BTMETER BT-770HC Digital Multimeter 6000Counts Auto Range
BTMETER BT-770HC Digital Multimeter 6000Counts Auto Range
Impossible de charger la disponibilité du service de retrait
PRODUCT DESCRIPTION
★ 【Non Contact Voltage Test(NCV)】When the detection of voltage is greater than 90V(RMS), keep close to the conductor, the instrument sensor will light and buzz.
★ 【Over load protection & continuity test】Use the ptc protection circuit for resistance, temperature and frequency measurement. If measured resistance less than 100Ω, the buzzer will sound.
★ 【Auto-ranging & auto-power off】DC & AC current (600A range with ac/dc current clamp adapter), resistance, capacitor, frequency, duty cycle, temperature, transistor hfe.
★ 【Low battery indication & blacklit lcd】3 1/2 digit lcd display for visibility in dimly lit areas. Feature a low battery indicator so you never accidentally run out of juice.
PRODUCT FUNCTION
★Accurately measures AC/DC Voltage; AC/DC Current; Resistance, Capacitor, Frequency and Temperature
★Transistor hFE Test/ Non Contact AC Voltage (NCV) Test/ Diode assembly Test
★Features Data Hold, LED Auto Back Light, Auto Power Off, Continuity Buzzer, ℃ and ℉ Select; True RMS.
★With Function Switch Indication Lamp, Mechanical Blocking System, Max/Min and Relative Value Test
PRODUCT SPECIFICATION
| Max LCD Display | 6000 Counts Digit |
| DC Voltage Range | 60mV/600mV/6V/60V/600V/1000V |
| AC Voltage Range | 60mV/600mV/6V/60V/600V/750V |
| DC Current Range | 600uA/6000uA/60mA/600mA/6A/20A |
| AC Current Range | 600uA/6000uA/60mA/600mA/6A/20A |
| Capacitor | 9.999nF~99.99mF |
| Frenquency |
9.99Hz/99.99Hz/999.9Hz/9.999KHz/99.99KHz/ 999.9KHz/9.999MHz |
| Resistance Range | 600/6K/60K/600K/6M/60M |
| Temperature Range | -20℃~1000℃/-4℉~1832℉ |
| Duty Cycle | 0.1%~99.9% |
| Transistor hFE Test Range | 0~1000; lb=10μA, Vce=1.8V Approx. |
| Weight | 1.8 pounds |
| Dimension | 7.7*3.5*1.6 inches |
