BTMETER BT-39B Digital Multimeter DC/AC Voltage Current Meter Resistance
BTMETER BT-39B Digital Multimeter DC/AC Voltage Current Meter Resistance
픽업 사용 가능 여부를 로드할 수 없습니다.
DESCRIPTION:
This portable multimeter with stable performance and anti-dropping capacity, uses 2000 counts digit LCD monitor to offer clear readings, giving excellent performance and exquisite making as a handy utility instrument.
FEATURES:
♦ Used to test DC & AC voltage, DC & AC current, resistance, temperature, battery test, positive diode.
♦ Voltage fall and audible continuity.
♦ 2000 counts digit LCD monitor with character 25mm high offers clear readings.
♦ 5 keys: some test functions selections, unit switch, backlight on-off, test modes switch, maximum.
♦ Value & display value hold.
♦ DC/AC & ℃/℉ unit switchable, manual/auto test modes switchable.
♦ Battery test: with green/yellow/red lights to clearly show the battery state.
♦ The anti-slip cover with test probe slots can protect multimeter and organize probes as well.
♦ A collapsible back bracket provide good support.
♦ Precision circuit board & overload PROTECTIONS.
♦ Comes with a wrist strap for your convenient carry and operation.
SPECIFICATIONS:
DC Voltage Range: 200mV/2V/20V/200V/600V
DC Voltage Resolution: 0.1mV/1mV/10mV/100mV/1V
AC Voltage Range: 2V/20V/200V/600V
AC Voltage Resolution: 1mV/10mV/100mV/1V
DC Current Range: 200μA/2000μA/20mA/200mA/2A/10A
DC Current Resolution: 0.1μA/1μA/10μA/100μA/1mA/10mA
AC Current Range: 200μA/2000μA/20mA/200mA/2A/10A
AC Current Resolution: 0.1μA/1μA/10μA/100μA/1mA/10mA
Resistance Range: 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ
Resistance Resolution: 0.1Ω/1Ω/10Ω/100Ω/1kΩ/10kΩ
Temperature Range: -20~150°C, 150~1000°C; -4~302°F, 302~1832°F
Temperature Resolution: 1℃; 1℉
Battery Test Range: 1.5V/6V/9V/12V
Battery Test Load Current: Approx. 10mA/100mA/10mA/200mA
Battery Test Resolution: 1mV/10mV/10mV/10mV
LED Light Range: 1.5V/6V/9V/12V
OTHER PARAMETERS:
Material | Plastic |
Color | Black+Orange |
Display | LCD display with backlight |
Power Supply | 1 x 9V 6F22 Battery (Not included) |
Screen Size | 5 x 3 cm / 2 x 1.2in |
Item Size | 14.5 x 10 x 3.5cm / 5.7 x 3.9 x 1.4in |
Item Weight | 207g/7.3oz |
Package Size | 18 x 12 x 5.8cm / 7.1 x 4.7 x 2.3in |
Package Weight | 344g/12.1oz |
PACKAGE INCLUDED:
1 x HoldPeak HP-39B Backlight Digital Multimeter
1 x Pair of Test Leads
1 x "K" Type Thermocouple Sensor Probe
1 x Wrist Strap
1 x User Manual
